詳細介紹
  • Auto-zero function
  • Easy to operate thanks to advanced electronic circuits like our proprietary auto-zero system.
  • Easy setting of the sample tube
  • A sample gauge provided on the surface of BR-501, which indicates the proper sample volume to be inspected. Only simple action is required to set the capillary tube into the holder.
  • Handles hemolysis and turbidity easily.
  • Careful selection of the dual wavelength color filters and the combination of electronic technology minimize the interference of hemolysis and turbidity.
    Particularly suitable for jaundice examinations of neonates.
  • Flexible power source
  • Power requirement is flexible from 100 to 240 VAC.
  • Alarm lamp informs user of abnormalities
  • Alarm lamp signals hemolysis of 300mg/dl or more.
  • Easy lamp replacement
  • Exchange procedure of the lamp is simplicity itself.
Specifications
Method Dual Wavelength (461 nm, 551 nm)
Measurement Range 0 - 30 mg/dL(Total bilirubin)
Correcting hemolysis 0 - 250 m/dL
Measuring accuracy ± 5 %
Sample Volume 50 - 60 μL
Display 3 1/2 digits 7 segment red LED
Sample Container Hematocrit capillary tube(Heparinized)
Light source Tungsten lamp
Detector High sensitivity silicon photocell
Power 100 - 240 VAC 50/60 Hz
Dimensions 280 (W) X 230 (D) X 120 (H) mm
Weight Around 3.4 kg (main body)

Standard Accessories
Standard solution(ABY) 2 bottles
Capillary tube(Heparinized, Red) 1 vial(100pcs)
Capillary tube(Plain, Blue) 1 vial(100pcs)
Clay sealer(Wax Plate) 1 pc
Spare lamp 1 pc
Fuse 2 pcs
Dust Cover 1 pc
Power cord 1 copy
Operation manual 1 copy
